DB-04
Degol
| Quantity: | |
|---|---|
double brass door bolts
This stainless steel indicator bolt offers a premium solution for privacy, featuring a high-visibility vacant engaged door lock signal that ensures user comfort in busy commercial restrooms. Its robust heavy duty door bolt construction provides exceptional durability and security, making it the perfect public toilet cubicle latch for modern office buildings, malls, and restaurants.
Brand | Degol |
Product name | Stainless Steel Slide Bolt Door Latch with Open/Close Indicator | Heavy Duty Security Door Bolt |
Finish | SSS, PSS,AB,AC |
Product Model | DB-04 |
Size | 6”,8”,10”,12” |
Surface | Silver/customizable |
Material | Stainless steel |
Suit for | wood door, metal door, interior door, exterior door |
OEM | Welcome |
Sample | Free |
1.Mark the Spindle Hole: Choose your desired height on the door. Measure 34mm from the door edge and mark this spot. This is where the spindle (the rod connecting the handle to the indicator) will pass through.
2.Drill the Hole: Use a 12mm drill bit to drill a hole through the door.
Pro Tip: To prevent the wood from splintering, stop drilling just as the tip of the bit pokes through the other side, then finish the hole by drilling from the outside toward the inside.
3.Prepare the Spindle: Insert the spindle through the hole. Depending on your door thickness, you may need to cut the spindle with a hacksaw. It should protrude about 10mm from the outside face of the door.
4.Mount the Indicator (Outside): Ensure the indicator is set to "Vacant" (Green/Blue) and the internal handle is in the open position. Slide the indicator plate onto the spindle on the outside of the door, mark the screw holes, and fix it in place.
5.Mount the Lock Body (Inside): Align the main lock body over the spindle on the inside of the door. Ensure it is level, mark the four corner holes, and secure it using the provided screws.
6.Install the Keeper (Frame): Close the door and slide the bolt into the "Locked" position. Place the metal keep (the small bracket) on the door frame where the bolt lands. Mark the holes and screw it into the frame.
1.General Operation
To Lock: Once inside, rotate the internal handle 90 degrees. You will feel a solid "click" as the deadbolt slides into the keeper. The external indicator will automatically flip from Green (Vacant) to Red (Engaged).
To Unlock: Rotate the handle back to the vertical position. This retracts the bolt and changes the external signal back to Green, signaling to others that the room is free.
2.Emergency Access
One of the most important features of this lock is the external emergency release. If someone (like a child or an elderly person) becomes trapped or unresponsive inside:
Locate the small slotted circular dial on the outside indicator face.
Insert a flat-head screwdriver or a small coin into the slot.
Turn the dial to manually retract the bolt from the outside.
3.Maintenance Tips
Cleaning: Since it is made of stainless steel, simply wipe it with a damp cloth and mild soap. Avoid abrasive cleaners or bleach, as these can scratch the finish.
1.Under 12mm: The door might be too thin for the screws to grip securely without poking through the other side.
2.12mm to 40mm: This is the "sweet spot" for this specific model.
3.Over 45mm: You will likely need to replace the included spindle with a longer one.
Yes, this product is crafted from high-grade 304 stainless steel, providing excellent corrosion resistance and durability, making it suitable for both interior and exterior applications.
The product features a premium Satin Brushed Finish. This modern look hides fingerprints and scratches much better than polished finishes and matches perfectly with other brushed nickel or steel hardware.
1. Professional Build Quality
Unlike plastic or zinc-alloy alternatives, Degol uses 304-grade stainless steel. This makes the bolt:
Corrosion-Resistant: Ideal for high-humidity environments like bathrooms or coastal areas.
Highly Durable: Rated for high-frequency use in busy public areas (malls, airports, offices).
Easy to Sanitize: The smooth metallic surface is resistant to harsh cleaning chemicals, ensuring a hygienic touchpoint.
2. Safety-First "Emergency Release"
This is a critical feature for public safety. The external side includes a coin-slot emergency release. If a child, elderly person, or someone in a medical emergency becomes trapped inside, the door can be unlocked from the outside in seconds using a simple coin or flathead screwdriver.
3. Universal Surface-Mount Design
Many locks require complex "mortising" (hollowing out the door), which can weaken the structure. Degol’s design is surface-mounted, meaning:
It fits almost any door thickness
.
It is much faster to install for DIYers or contractors.
It works on various materials, including timber, metal, and thin partition laminates.
4. Clear Visual Privacy
The bold Green (Vacant) / Red (Engaged) indicator is designed for instant recognition from a distance. This "at-a-glance" status prevents awkward handle-pulling by others, ensuring a much better user experience in shared spaces.
