DH1036
Degol
| Quantity: | |
|---|---|
The DH1036 Stainless Steel Piano Hinge is a continuous hinge designed for compatible doors, cabinets, access panels and industrial enclosures requiring an extended hinge connection along the mounting edge.
Also known as a continuous hinge or long hinge, a piano hinge consists of two elongated mounting leaves connected by a series of interlocking knuckles and a central pivot pin.
Unlike conventional butt hinges installed at separate points along a door edge, a continuous hinge extends along a substantial portion of the mounting edge. This construction can help distribute the hinge connection along the door or panel, subject to the hinge design, mounting substrate, fasteners and application loads.
The DH1036 is intended for evaluation in architectural hardware, industrial equipment, storage cabinets, access hatches, metal enclosures and other applications where continuous hinge construction is preferred.
The supplied reference drawing illustrates a product series with different widths and lengths, together with dimensional symbols for overall length, open width, leaf thickness, knuckle length, mounting-hole diameter, hole spacing and pivot-pin diameter.
The reference image lists common stock lengths of approximately 1029 mm and 1829–1830 mm, with multiple width and material options found in comparable market products. These are market benchmarks rather than confirmed factory specifications for DH1036.
For international hardware distributors, cabinet manufacturers, industrial enclosure suppliers and architectural door hardware wholesalers, Jiangmen Degol Hardware Co., Ltd. welcomes enquiries regarding specifications, available materials, mounting-hole configurations, samples and wholesale pricing.
The DH1036 is a continuous piano hinge designed to connect a compatible door or panel to a frame or supporting structure through an elongated pivoting joint.
Its principal components typically include two long hinge leaves, interlocking knuckles and a central hinge pin.
The two leaves are fixed to the corresponding door and frame surfaces. The central pin provides the pivot axis around which the door or panel rotates.
Continuous hinges are frequently selected when a long, uninterrupted hinge connection is preferred over multiple separately mounted hinges.
Continuous hinge construction
Two elongated mounting leaves
Interlocking knuckle structure
Central pivot pin
Long-edge door or panel mounting
Available in multiple widths and lengths, subject to product range
Potential drilled, countersunk or undrilled configurations
Suitable for compatible industrial and architectural applications
The actual DH1036 material grade, pin construction, maximum load, corrosion resistance and mounting-hole configuration must be confirmed against the official factory specification.
| Specification Item | Details |
|---|---|
| Model Number | DH1036 |
| Product Name | Stainless Steel Piano Hinge |
| Alternative Name | Continuous Hinge |
| Hinge Type | Continuous Pivot Hinge |
| Main Construction | Two Leaves, Interlocking Knuckles and Central Pin |
| Main Material | Stainless Steel – Grade to Be Confirmed |
| Reference Material Options | AISI 304 / 316 Stainless Steel, Carbon Steel, Aluminum and Brass in the Broader Market |
| Overall Length | To Be Confirmed |
| Reference Stock Lengths | 1029 mm and Approximately 1829–1830 mm |
| Open Width | Reference Range: 25.4–76.2 mm; Some Market Products Offer Wider Options |
| Leaf Thickness | Reference Range: 0.7–2.0 mm |
| Pin / Hub Diameter | Reference Range: 3.2–10 mm |
| Knuckle Length | Common Reference Range: 6–20 mm |
| Mounting Hole Diameter | Common Reference Range: 3.5–6.5 mm |
| Hole Spacing | Common Reference Range: 25–100 mm |
| Mounting Hole Style | Standard or Countersunk, Subject to Configuration |
| Drilling Options | Undrilled, Drilled or Custom Perforations |
| Installation Method | Screw or Other Approved Fixing Method |
| Applications | Doors, Cabinets, Hatches, Access Panels and Enclosures |
| OEM / ODM | Subject to Feasibility |
| MOQ | To Be Confirmed |
| Dimension Unit | mm |
Specification Notice: The numerical ranges above are drawn from the supplied market reference illustration. They do not constitute verified DH1036 production dimensions, material specifications or performance ratings.
The supplied DH1036 reference drawing presents the continuous hinge in a product-series view, top view with the hinge opened flat, side view with the hinge closed and end view looking along the pivot-pin axis.
The drawing uses six primary dimensional symbols to describe the hinge geometry.
| Symbol | Dimension Description | Reference Specification |
|---|---|---|
| L | Overall Length | Market stock examples: 1029 mm and approximately 1829–1830 mm |
| W | Open Width Across Both Leaves | Common range: 25.4–76.2 mm; wider options may exist |
| T | Leaf Thickness | Common range: 0.7–2.0 mm |
| P | Pin / Hub Diameter | Common range: 3.2–10 mm |
| K | Knuckle Length | Common range: 6–20 mm |
| H | Mounting Hole Diameter | Common range: 3.5–6.5 mm |
| S | Mounting Hole Spacing | Common range: 25–100 mm |
Overall length refers to the end-to-end length of the continuous hinge assembly.
The reference image lists two common stock-length examples:
1029 mm, approximately 40.5 inches
1829–1830 mm, approximately 72 inches
Actual DH1036 stock lengths, cutting tolerances and custom-length availability must be confirmed with DEGOL.
Open width is the total width across both mounting leaves when the hinge is laid flat.
The illustrated market reference shows a common range of 25.4–76.2 mm, although some manufacturers offer wider configurations.
The correct width depends on the door-edge geometry, available mounting surface and required hinge coverage.
Leaf thickness refers to the thickness of each mounting leaf.
The reference drawing lists a common market range of 0.7–2.0 mm.
The appropriate thickness depends on the intended load, hinge construction, mounting substrate and required durability.
This dimension describes the diameter of the central pin or the referenced hub feature, according to the manufacturer's dimensional convention.
The reference illustration lists a market range of 3.2–10 mm.
The exact measurement point should be confirmed in the official engineering drawing.
Knuckle length refers to the length of an individual knuckle section along the pivot axis.
The reference image lists common market values of approximately 6–20 mm.
Knuckle geometry can vary by hinge model and manufacturing design.
Mounting-hole diameter describes the diameter of the fixing opening in the hinge leaf.
The reference image lists common values of approximately 3.5–6.5 mm for comparable products.
Countersunk versions may use a separate countersink diameter and angle.
Hole spacing describes the distance between adjacent mounting-hole centers.
The reference image lists common spacing of approximately 25–100 mm.
The actual drilling pattern may vary with hinge length, fixing requirements and customer drawings.
Depending on the actual DH1036 product range, buyers may enquire about:
Undrilled continuous hinges
Standard drilled mounting holes
Countersunk mounting holes
Customized hole diameters
Customized hole spacing
Cut-to-length requirements
Alternative open widths
Different leaf thicknesses
Availability must be confirmed before production planning.
All dimensions are expressed in millimeters.
The supplied drawing is marked as a market benchmark.
Exact DH1036 dimensions have not been verified.
Hole patterns and countersink geometry must be confirmed.
Material grade and finish require factory confirmation.
Cutting tolerances and pin-retention arrangements are not specified.
Obtain the approved product drawing before machining or mass production.
Stainless steel is the stated material category for the DH1036. The reference illustration lists AISI 304 and AISI 316 stainless steel among the materials available in the broader continuous-hinge market.
The actual grade used in DH1036 has not been verified.
| Component / Feature | Description |
|---|---|
| Hinge Leaves | Stainless Steel – Grade to Be Confirmed |
| Knuckles | Material to Be Confirmed |
| Central Pivot Pin | Material to Be Confirmed |
| Reference Stainless Steel Grades | AISI 304 / 316 in Comparable Products |
| Corrosion Resistance | Depends on Material Grade, Finish and Testing |
Stainless steel continuous hinges are commonly considered for applications where corrosion resistance, structural consistency and a metallic finish are required.
The actual corrosion performance depends on the selected stainless steel grade, manufacturing process, surface condition and operating environment.
AISI 304 is widely used in general architectural and industrial hardware applications. Its suitability depends on environmental conditions and the relevant design requirements.
AISI 316 may be considered for applications requiring improved resistance to certain corrosive environments, including some coastal and marine conditions.
However, the material grade must be confirmed, and the use of AISI 316 must not be assumed for DH1036 without manufacturer documentation.
Buyers may enquire about natural stainless steel, polished stainless steel, nickel, brass, bronze, black or other surface treatments, subject to actual product availability.
For demanding industrial or outdoor applications, request confirmation of:
Stainless steel grade
Pivot-pin material
Surface finish specification
Corrosion-resistance requirements
Material certificates, where applicable
Compatibility with the operating environment
The DH1036 Stainless Steel Piano Hinge can be evaluated for applications requiring an extended hinge connection along a door or panel edge.
Continuous hinges can be considered for compatible metal doors where an extended mounting connection is required.
Suitable for evaluation on compatible wooden doors, subject to door weight, mounting strength and screw requirements.
Continuous hinges can provide an elongated pivot connection for cabinet doors and selected storage units.
The hinge can be evaluated for equipment access panels requiring regular opening and closing.
Potential applications include compatible electrical, mechanical and equipment enclosures, subject to environmental and design requirements.
Continuous hinges can be considered for compatible inspection hatches and service-access openings.
Stainless steel continuous hinges may be evaluated for selected marine applications after confirming the material grade, corrosion requirements and installation conditions.
The hinge may be suitable for selected folding furniture and extended panel connections where the geometry and load rating are appropriate.
The DH1036 can be considered by hardware wholesalers, door manufacturers, cabinet manufacturers and industrial equipment suppliers sourcing continuous hinges.
| Door / Panel Type | Suitability Considerations |
|---|---|
| Wooden Doors | Confirm door weight and screw-holding strength |
| Metal Doors | Verify mounting geometry and fixing method |
| Cabinet Doors | Check hinge width, panel size and operating load |
| Industrial Enclosure Doors | Confirm environmental and equipment requirements |
| Access Panels | Verify opening clearance and required service access |
| Inspection Hatches | Check panel dimensions and hinge orientation |
| Marine Panels | Confirm stainless steel grade and corrosion requirements |
| Folding Furniture Panels | Verify folding geometry and mounting strength |
| Custom Fabricated Doors | Match the approved technical drawing |
Before selecting DH1036, confirm:
Door or panel length
Required open width
Leaf thickness
Door weight and operating loads
Mounting substrate and fixing strength
Pivot-pin configuration
Mounting-hole diameter and spacing
Required surface finish
Environmental exposure
Required cycle life and maintenance conditions
Continuous hinge selection should be based on the complete assembly rather than hinge length alone. Door weight, mounting fasteners, substrate strength and installation quality all affect performance.
The following is a general installation overview for a screw-mounted continuous hinge. The actual DH1036 should be installed according to its approved product drawing and manufacturer's instructions.
Step 1: Confirm Hinge Specifications
Verify the actual hinge length, open width, leaf thickness, pin diameter and drilling configuration.
Step 2: Inspect the Door and Frame
Check the mounting surfaces for flatness, structural integrity and sufficient fixing depth.
Step 3: Position the Hinge
Align the hinge along the intended door edge or panel connection.
Confirm that the hinge axis is correctly positioned for the required opening direction.
Step 4: Mark the Mounting Holes
Use the actual product or approved template to mark the fixing-hole locations.
Do not rely on generic market hole-spacing values as production drilling instructions.
Step 5: Prepare the Fixing Points
Prepare pilot holes or other approved mounting features according to the door material and fastener specification.
Step 6: Secure the First Leaf
Attach one hinge leaf to the door or panel using the specified fasteners.
Ensure that the leaf lies flat against the mounting surface.
Step 7: Align the Second Leaf
Position the second leaf on the corresponding frame or supporting surface while maintaining alignment along the pivot axis.
Step 8: Secure the Second Leaf
Install the remaining fasteners according to the approved fixing sequence.
Avoid overtightening or distorting the hinge leaves.
Step 9: Test Door Movement
Open and close the door or panel through its intended travel range.
Check for binding, uneven movement, interference or abnormal noise.
Step 10: Complete Final Inspection
Verify fastener security, pin retention, hinge alignment and the stability of the mounting substrate.
Long continuous hinges may be heavy or difficult to handle, particularly on large doors and panels.
Provide adequate support during installation. For heavy or safety-critical assemblies, obtain the manufacturer's load recommendations and use qualified installers.
The elongated hinge design provides a continuous pivot connection along a substantial portion of the door or panel edge.
Compared with several separately mounted butt hinges, a continuous hinge offers a longer mounting interface when installed in a suitable configuration.
Stainless steel construction is relevant to architectural and industrial applications requiring a metallic hinge material, subject to grade verification.
The broader market offers different stock lengths and custom-length possibilities. Actual DH1036 options should be confirmed with DEGOL.
Different open widths may accommodate different door-edge geometries and mounting requirements.
Drilled, countersunk and undrilled configurations are common in the continuous-hinge market and may be considered for the DH1036 product range.
Continuous hinges are used across doors, cabinets, access panels, enclosures and selected furniture applications.
Stainless steel finishes can complement contemporary architectural hardware and industrial equipment.
The product category is relevant to door manufacturers, cabinet manufacturers, industrial hardware distributors and project procurement teams.
DEGOL welcomes enquiries regarding material requirements, dimensions, drilling patterns, finishes and packaging.
Jiangmen Degol Hardware Co., Ltd. welcomes OEM and ODM enquiries for the DH1036 Stainless Steel Piano Hinge and related continuous-hinge products.
Material Grade
Buyers may request confirmation of the standard stainless steel grade or submit alternative material requirements for evaluation.
Overall Length
Custom lengths may be discussed according to product design, tooling and production feasibility.
Open Width
Buyers can submit the required open width for technical review.
Leaf Thickness
Alternative leaf thicknesses may be evaluated according to the intended application and manufacturing requirements.
Mounting Hole Pattern
Customers may submit hole diameter, spacing and countersink requirements.
Undrilled Versions
Buyers can enquire about undrilled hinge leaves for subsequent machining or application-specific fabrication.
Surface Finish
Natural stainless steel, polished stainless steel and other decorative finishes may be discussed according to availability.
Branding and Private Label
Product identification and private-label requirements can be reviewed.
Customized Packaging
Retail boxes, product labels, export cartons and project-specific packing options may be discussed.
Technical Drawing Review
Customer drawings and application requirements can be submitted for feasibility assessment.
Sample Evaluation
Sample availability can be confirmed for customers who need to inspect dimensions, materials and installation fit before bulk purchasing.
All customization options, tooling requirements, MOQ and production lead times are subject to technical feasibility and commercial confirmation.
| Order Item | Details |
|---|---|
| Product Model | DH1036 |
| Product Name | Stainless Steel Piano Hinge |
| Product Type | Continuous Hinge |
| Brand | DEGOL |
| Product Category | Door Hinges / Industrial Hardware |
| Sales Type | Wholesale / Project Procurement |
| Standard Lengths | To Be Confirmed |
| Custom Lengths | Subject to Feasibility |
| Sample Availability | Contact DEGOL |
| MOQ | 1000pcs |
| Wholesale Price | Based on Material, Dimensions and Quantity |
| Customized Packaging | Subject to Order Requirements |
| Private Label | Enquiries Welcome |
| Shipping Method | Subject to Destination and Agreement |
| Payment Terms | Confirmed During Quotation |
| Inspection Requirements | Subject to Order Specifications |
Contact DEGOL with model number DH1036.
Specify the required quantity and destination market.
Confirm the required length and open width.
Specify the preferred material grade and finish.
Confirm leaf thickness and pin configuration.
Submit the required mounting-hole pattern or drawing.
Request an official technical drawing or sample.
Confirm MOQ, pricing, packaging and lead time.
Approve the final product specification before production.
Jiangmen Degol Hardware Co., Ltd. serves the architectural hardware market and welcomes product enquiries from international wholesalers, door manufacturers, cabinet manufacturers, industrial equipment suppliers and project buyers.
For the DH1036 continuous hinge, DEGOL can be contacted regarding available product specifications, material options, mounting-hole configurations, technical drawings, samples and wholesale purchasing requirements.
Product Specification Enquiries
Buyers may request verified dimensions, material grades and application information.
Technical Drawing Support
Official drawings and mounting details can be requested for product evaluation and installation planning.
Material and Finish Information
Customers can confirm the actual stainless steel grade, pivot-pin material and available finishes.
Mounting Configuration Review
Buyers may submit required hole patterns, countersink dimensions and other mounting details.
Sample Requests
Sample availability, costs and delivery arrangements can be discussed.
OEM / ODM Projects
Customization requests involving dimensions, materials, finishes, branding and packaging may be evaluated.
Wholesale Quotations
Commercial quotations can be requested according to the final product specifications and order quantity.
Export Order Coordination
Packaging, shipment requirements and commercial documentation can be discussed with DEGOL.
Specific factory capacity, production equipment, quality certifications, material-testing capabilities and delivery commitments should be confirmed directly with the company.
Company: Jiangmen Degol Hardware Co., Ltd.
Website: https://www.degolhardware.com/
Email: info@degolhardware.com
WhatsApp: +86 13725946499
Q1: What is the DH1036 Stainless Steel Piano Hinge?
The DH1036 is a continuous-hinge product intended for compatible doors, cabinets, access panels and industrial enclosures.
Q2: What is a piano hinge?
A piano hinge, also known as a continuous hinge, uses two elongated leaves connected by interlocking knuckles and a central pivot pin.
Q3: What are the reference stock lengths shown in the drawing?
The reference illustration lists 1029 mm and approximately 1829–1830 mm as common market stock lengths. Actual DH1036 lengths must be confirmed with DEGOL.
Q4: What is the available open width?
The drawing shows a common market range of 25.4–76.2 mm, with wider options available from some manufacturers. The actual DH1036 range has not been confirmed.
Q5: What leaf thicknesses are available?
The reference image lists 0.7–2.0 mm as a common market range. Confirm the available DH1036 thicknesses before ordering.
Q6: Is DH1036 made of AISI 304 stainless steel?
AISI 304 is listed among comparable market materials. The actual DH1036 material grade must be confirmed with DEGOL.
Q7: Can the hinge be manufactured in AISI 316 stainless steel?
AISI 316 is used in some continuous-hinge products. Availability for DH1036 requires confirmation from DEGOL.
Q8: What mounting-hole configurations are available?
The broader market includes undrilled, drilled and countersunk versions. Actual DH1036 configurations should be confirmed before placing an order.
Q9: Can the hinge be cut to a custom length?
Custom lengths may be discussed, subject to the actual product construction, manufacturing feasibility and order requirements.
Q10: Is the DH1036 suitable for heavy doors?
Heavy-door suitability has not been established from the reference drawing. Request the manufacturer's load rating and installation recommendations before selection.
Q11: Does a continuous hinge distribute the door load evenly?
Its extended mounting interface can help distribute the connection along the door edge, but actual load distribution depends on the hinge, fasteners, mounting substrate, installation quality and door design.
Q12: Is the hinge suitable for marine applications?
It may be evaluated for suitable marine applications, but the actual material grade, corrosion requirements and installation environment must be verified.
Q13: What finishes are available?
Natural stainless steel and polished stainless steel are common market options. Other finishes may be available, subject to confirmation of the actual DH1036 product range.
Q14: Can I request customized mounting-hole spacing?
Buyers can submit their required hole pattern for technical review, subject to manufacturing feasibility.
Q15: Does DEGOL accept OEM / ODM orders?
DEGOL welcomes OEM / ODM enquiries regarding dimensions, materials, finishes, drilling configurations, branding and packaging.
Q16: Can I request a sample before placing a bulk order?
Contact DEGOL to confirm sample availability, costs and shipping arrangements.
Q17: What is the MOQ for DH1036?
The minimum order quantity must be confirmed directly with DEGOL according to the selected specification.
Q18: How can I request wholesale pricing?
Send DEGOL the model number DH1036, required dimensions, material grade, finish, quantity and destination market through WhatsApp or email.
Looking for a stainless steel continuous piano hinge for your architectural door hardware, cabinet hardware or industrial enclosure product range? Contact DEGOL Hardware for product specifications, technical drawings, available materials and finishes, mounting-hole options, sample information and wholesale pricing.
Product Model: DH1036
Product Name: DH1036 Stainless Steel Piano Hinge
Company: Jiangmen Degol Hardware Co., Ltd.
WhatsApp: +86 13725946499
Website: https://www.degolhardware.com/
Email: info@degolhardware.com
Request Your DH1036 Stainless Steel Piano Hinge Wholesale Quote Today.
Contact DEGOL on WhatsApp – Request DH1036 Wholesale Pricing
