Modern Zinc-Aluminum Door Handle, Sleek Chrome Finish for Home & Office
| Specific Parameter | English Description |
| Main Material | Zinc-Aluminum Alloy (Zinc Alloy + Aluminum Alloy Composite) |
| Opening Angle | 90° / 180° Rotation |
| Load Capacity | Static Load: ≥ 1500N, Dynamic Load: ≥ 800N (EN 1906 Standard) |
| Service Life | ≥ 200,000 Cycles of Opening & Closing |
| Fire Rating | Optional: 30min / 60min / 90min Fire Resistance (BS EN 1634-1) |
| Suitable Door Type | Wooden Door, Metal Door, PVC Door, Aluminum Alloy Door, Glass Door (with Adapter) |
| Suitable Door Thickness | 35mm - 50mm (Standard), 30mm - 60mm Customizable |
| Lock Body Compatibility | Fits Euro Profile Cylinder, Mortise Lock, Passage Lock, Privacy Lock |
| Single Packing | Blister Card / Color Box / Poly Bag (Customizable) |
| Outer Carton | 50pcs / Carton, 100pcs / Carton (Standard) |
| MOQ | 500pcs / Model (Negotiable for Trial Order) |
Zinc-Aluminum Door Handle Features:
Material Advantage: Made of high-quality zinc-aluminum alloy, combining the high strength of zinc alloy and the light weight of aluminum, with excellent anti-rust and anti-corrosion performance.
Surface Treatment: Multi-layer electroplating process, uniform color, scratch-resistant, long-lasting gloss, easy to clean and maintain.
Universal Design: Reversible left/right handed, fits most standard door thickness and lock bodies, easy to install for DIY and professional workers.
High Durability: Passed 200,000+ opening and closing cycle tests, stable performance, suitable for residential, commercial, hotel and other high-frequency use scenarios.
Safety Compliance: Meet international CE, EN 1906 and other standards, optional fire rating, safe and reliable for public and private buildings.
Zinc-Aluminum Door Handle Appilication:
Zinc-Aluminum Door Handle Installation Steps:
Mark the position (900-1100mm from the ground), align the mounting plate and mark screw holes.
Fix the mounting plate with screws (do not over-tighten).
Tighten the fixing screws, test the handle rotation (smooth and flexible).
FAQ
Why are my hands drooping?
This is the most common fault.Usually, it is due to the fatigue or breakage of the internal return spring, or the loosening of the fixing screws.
Many lever handles are reversible (Reversible), without distinguishing left or right. But some handles with specific arcs or asymmetrical designs must be confirmed at the time of purchase whether they are "left-handed" or "right-handed".
Do you need to drill new holes during installation?
If you are replacing the old spherical handle (Knob), the lever handle usually uses a standard 2-1/8 inch (about 54mm) hole diameter, and most can be seamlessly replaced directly.
Note: The only thing that needs to be confirmed is the backset (offset), that is, the distance from the center of the hole to the edge of the door, which is usually 60mm or 70mm.
Are lever handles really easier for pets to open?
Yes. Since the lever handle only requires downward pressure, intelligent pets (especially large and medium-sized dogs) can open the door by standing upright and pressing down on the handle.
Solution: If you want to prevent pets or children, it is recommended to install it at a higher position or choose a model with a rotating lock mechanism.
How to choose the material? Which one doesn't fade?
Stainless steel (Grade 304): The most durable, does not fade, has strong rust prevention ability, and is suitable for bathrooms.
Zinc alloy: The color is the most diverse (matte black, brushed gold, etc.), but the coating may wear off over time.
Solid brass: The feel is the heaviest, the texture is the best, and it has certain natural antibacterial properties.
